- SmartOne
- Satellite-Managed Asset-Ready Tracker
- Designed for the intelligent management of powered and non-powered fixed and movable assets, SmartOne is a practical solution for engine runtime reporting and major fault monitoring for portable construction equipment as well as tracking intermediate bulk containers, vehicles and boats.
Home > TERMINALS > SmartOne
- SmartOne
- The "asset ready" design allows it to be easily installed and field managed without the need for harnesses, antennas, or external power. The SmartOne is powered by 4 "off-the-shelf" AA 1.5V lithium batteries providing 3+ years of battery life and removes the need to purchase expensive proprietary batteries for replacement.
The SmartOne utilizes motion sensors, comparative GPS positions and custom configured sensors to gather and transmit asset status information. Each SmartOne is configured to track its asset's specific needs and provide intermediate and emergency alerts by email and/or text/cellular.
- Features
- Quick installation: Use industrial adhesives, brackets or screw mounts for installation
- Simple packaging: Requires no harnesses, external power or external antenna
- Automatic alerts: Change of location sensing sends alerts if asset moves outside of pre-determined range
- Messaging cost reduction mode: Reduced satellite messaging if asset remains in same location for a pre-determined period of time
- Hardware on/off feature: Allows the unit to initiate GPS re-centering functionality
- Accepts serial signals (TTL) from external inputs
- Benefits
- Operates on external line power from 10 to 48 volts DC
- “Asset-ready” design: Allows for easy installation and field management without the need for antennas or external power
- Standard Messaging includes: Wake, GPS locate, transmit location, resume sleep and additional 12 programmable sleep and timeof-wake settings
- Messaging Cost Reduction Feature: Reduces satellite messaging if asset remains in same location or cannot obtain a GPS fix (indoors)
- Configuration Software
- Software configuration tool easily installs on PCs
- SmartOne LP Setup Includes
- Up to 12 different reporting times
- Interval or 24 hour operation mode
- Alternate reporting scheduling
- Low battery message
- Motion Sensor/Vibration parameter and scheduling
- Contact closure parameters
- Diagnostic messages
- Operating Specifications
| Dimensions | 3.25”H x 6.5”W x 1.0” D |
|---|---|
| Weight | 13.5oz/385g (with 4 batteries and mounting hardware) |
| Operating Temperature | -30° to +60° C Note: The unit shall remain operational over the -40° to +85°C range, though may experience battery life and RF signal degradation |
| Line power | Up to 48 volts DC |
| Battery Type | 4 AA 1.5V lithium Provides 3+ years of battery life Removes the need to purchase expensive proprietary batteries for replacement |
| Certifications | UL913 and CSA C22.2 No. 157 Certified Intrinsically Safe for use in Class I, Division 1 Groups A, B, C, D environments for US and Canada ANATEL Certification for Brazil (pending) FCC CFR Parts 15 and 25 Industry Canada CE Mark (European Certification) COFETEL |
| Standards | SAE J1455 MIL STD 810 NEMA 4X / IP68 RoHS Compliant |
| Satellite Technology | Global LEO Satellite operation using the Globalstar Simplex Data Network |
- Feature Set
- STANDARD MESSAGING
- Wake, GPS locate, transmit location, resume sleep
- Up to 12 programmable sleep time-of-wake settings
- ALTERNATIVE REPORTING:
- Alternate supervisory reporting schedule triggered by alarm or motion
- Transmits GPS location on alternate interval for programmed time or while alarm remains active
- INTEGRATED VIBRATION SENSOR
- Message on start and stop
- Engage interval override on motion for set time or while in motion
- Integrated Motion (Vibration) Sensor sends messages on start and stop motion event
- MESSAGING COST REDUCTION
- Reduced satellite messaging if asset remains in same location or cannot obtain a GPS fix (indoors)
- CHANGE OF LOCATION
- Theft recovery reporting based on distance moved
- Reduced messaging mode
- SERIAL COMMUNICATION CAPABILITY
- User defined messages
- Serial (TTL) I/O capability to interface with remote passive and smart sensors and deliver user defined messages
- Accessories
- USB Configuration Cable
- Combined Serial, LP, I/O Cable
